Connection Inlet-Outlet: 3"
Connection Type: BSP (Tapered)
Capacity Range: 0 - 894 lpm
Pump Head: 84 mwc
Max. Suction Lift: 6 - 8 m
Max. Solid Particle Size: 8 mm
Pump Casing Materials: Aluminum, Cast Iron, Stainless Steel (316)
Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santopren, EPDM
Air Line: Aluminum (Intermediate Bracket, Air Valve, Pilot Valve, Air Inlet Cap, Inner Chamber)
Air Connection: 3/4"
Max. Operating Air Pressure: 0-8,4 bar
Air Consumption: 33 - 235 m3/h
