Connection Inlet-Outlet: 2’’
Connection Type: Flange - BSP
Capacity Range: 0-565 lpm
Pump Head: 0-84 mwc
Max. Suction Lift: 6-8 m
Max. Solid Particle Size: 6 mm
Pump Casing Materials: Polyproplene, Black Polyproplene, PVDF(Kynar)
Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM
Air Connection: 3/4"
Max. Operating Air Pressure: 0-8,4 bar
Air Consumption: 33 - 169 m3/h
