Plastic Diaphragm Pumps

DP 02 Plastic Diaphragm Pumps

Diapump DP 02 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 1/4``-1/2’’

Capacity Range: 0-16 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 1 mm

Pump Casing Materials: Polyproplene, PVDF(Kynar)

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 03 Plastic Diaphragm Pumps

Diapump DP 03 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 1/4``-3/8’’

Capacity Range: 0-16 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 1 mm

Pump Casing Materials: Black Polyproplene

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 05 Plastic Diaphragm Pumps

Diapump DP 05 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 3/4''

Capacity Range: 0-57 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 3 mm

Pump Casing Materials: Polyproplene, Black Polyproplene, PVDF(Kynar)

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 06 Plastic Diaphragm Pumps

Diapump DP 06 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 3/4``-1/2’’

Capacity Range: 0-57 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 3 mm

Pump Casing Materials: Black Polyproplene

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 10 Plastic Diaphragm Pumps

Diapump DP 10 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 1’’

Capacity Range: 0-160 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 4 mm

Pump Casing Materials: Polyproplene, Black Polyproplene, PVDF(Kynar)

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 11 Plastic Diaphragm Pumps

Diapump DP 11 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 1’’

Capacity Range: 0-160 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 4 mm

Pump Casing Materials: Black Polyproplene

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 15 Plastic Diaphragm Pumps

Diapump DP 15 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 1½’’

Capacity Range: 0-400 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 6 mm

Pump Casing Materials: Polyproplene, Black Polyproplene, PVDF(Kynar)

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 20 Plastic Diaphragm Pumps

Diapump DP 20 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 2’’

Capacity Range: 0-565 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 6 mm

Pump Casing Materials: Polyproplene, Black Polyproplene, PVDF(Kynar)

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL

DP 30 Plastic Diaphragm Pumps

Diapump DP 30 Plastic Diaphragm Pumps

Connection Inlet-Outlet: 3’’

Capacity Range: 0-894 lpm

Pump Head: 0-84 mwc

Max. Suction Lift: 6-8 meter

Max. Solid Particle Size: 8 mm

Pump Casing Materials: Black Polyproplene

Pump Inner Materials: Neoprene, Buna-n, PTFE, FKM, Santoprene, EPDM

DETAIL
